Boring & grinding
BORING - FINISHING
BORING, OUTER and INNER CILINDRICAL GRINDING, SURFACES GRINDING |
|||
GEARBOX GRINDING, CRANKSHAFT GRINDING, HONNING |
|||
BORING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
1000 X1000 X 1000 Fmax=350mm |
0.015 mm |
1.6 |
|
900 X 6000 X 800 Fmax=250 mm |
0.01 mm |
1.6 |
|
OUTER CILINDRICAL GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=350 mm |
0.01 |
1.6 |
|
Fmax=500 mm |
0.015 |
1.6 |
|
INNER CILINDRICAL GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=350 mm |
0.01 |
1.6 |
|
Fmax=500 mm |
0.015 |
1.6 |
|
SPECIAL GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
1000 X 800 X 700 Fmax=250 mm |
0.01 |
1.6 |
|
SURFACES GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
1000 X 500 X 500 |
0.01 |
1.6 |
|
1250 X 3000 X 650 |
0.025 |
1.6 |
|
GEARBOX TETH GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=250 mm |
0.01 |
1.6 |
L= 400 mm |
THREAD GRINDING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=200 mm |
0.01 |
1.6 |
|
HONING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=50 mm |
0.01 |
0.3 - 0.8 |
L= 400 mm |
Fmax=100 mm |
0.015 |
0.3 - 0.8 |
L= 400 mm |
