Turning & Milling
TURNING - MILLING
TURNING OPERATION |
|||
INNER, OUTER and CONICAL TURNING, PROFILING, THREAD CUTTING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax=100 mm |
0.1 mm |
3.2 - 6.3 |
Lmax = 400 mm |
Fmax=400 mm |
0.1 mm |
3.2 - 6.3 |
Lmax = 1.000 mm |
Fmax=1600 mm |
0.15 mm |
3.2 - 6.3 |
Lmax = 6.000 mm |
Fmax=400 mm |
0.05 mm |
3.2 - 6.3 |
profiling by turning |
MILLING |
|||
VERTICAL, HORIZONTAL, PROFILING SURFACES |
|||
CIRCULAR SLOTTING, GEARBOXES, GEAR SHAPING |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
400 x 350 x 250 |
0.1 mm |
3.2 - 6.3 |
|
500 x 500 x 500 |
0.1 mm |
3.2 - 6.3 |
|
700 x 300 x 300 |
0.1 mm |
3.2 - 6.3 |
|
1200 x 1200 x 1200 |
0.05 mm |
3.2 - 6.3 |
|
1200 x 1200 x 2000 |
0.05 mm |
3.2 - 6.3 |
|
6000 x 2000 x 1500 |
0.05 mm |
3.2 - 6.3 |
|
Milling in coordonates |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
900 x 500 x 500 |
0.01 mm |
3.2 |
|
1400 x 800 x 700 |
0.01 mm |
3.2 |
|
Profiling by milling |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
800 x 800 |
0.01 |
3.2 |
|
Gearbox milling |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
Fmax = 250 |
0.1 mm |
3.2 |
|
Fmax = 320 |
0.1 mm |
3.2 |
|
Gearbox shaping |
|||
Dimension range |
Accuracy |
Roughness |
Observation |
F 600(module:1-6) |
0.1 mm |
3.2 |
|
